To install the processor, reverse the removal procedures.
NOTE: After installing a new processor onto the system board, update the system ROM to ensure that
the computer using the latest version of the BIOS.
Flex card
To remove the flex card, use this procedure and illustration.
Before removing the flex card, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 20).
2. Remove the access panel (see Access panel on page 21).
Remove the flex card:
1. Remove two Torx screws (1) that secure the card to the rear of the computer.
2. Disconnect the flex card cable from the system board connector labeled LINE OUT2 (2).
Flex card
51
