2. Slide the cage (2) toward the back of the computer, and then lift the cage (3) up and out of the
computer.
To replace the optical drive cage, reverse this procedure.
Rotating the power supply
To rotate the power supply upright, use this procedure and illustration.
Before rotating the power supply, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 20).
2. Remove the access panel (see Access panel on page 21).
Rotate the power supply:
■
Lift the front of the power supply to rotate it to the upright position.
44
Chapter 4 Removal and replacement procedures
