Table 2-1 Computer major components and their descriptions (continued)
Item Description
(6) Heat sink
(7) Processor
Intel® Core® i5-13500TE processor
Intel Core i5-13500E processor
Intel Core i3-13100TE processor
Intel Core i3-13100E processor
(8) System board
NOTE: System boards are available for computers with a non-Windows® operating system, Windows IoT, and
Windows.
(9) WLAN module
Intel Wi-Fi® 5 AX211 + Bluetooth® 5.2 (vPro)
Intel Wi-Fi 5 AX211 + Bluetooth 5.2 (non-vPro)
(10) Solid-state drive (M.2 2280, PCIe-4×4)
2 TB, TLC
1 TB, SS, TLC
1 TB
512 GB, TLC
512 GB, TLC, self-encrypting drive (SED)
512 GB
256 GB, self-encrypting drive (SED)
256 GB
(11) Rear flex card
Dual USB Type-A ports
USB Type-C with DisplayPort (15 W output)
USB Type-C with DisplayPort (27 W an d65 W output)
DisplayPort 1.4a
VGA
HDMI2.0b with HDR + HDCP 2.3
NIC 2.5 G
(12) Computer chassis
(13) Powered serial port
(14) Rear option card
Line out connector
3× 12 V USB ports
8 Chapter 2 Illustrated parts catalog
