3. Raise the rack by lowering the leveling feet, raising the casters approximately 64 mm (025 in) o the floor.
4. Install one stabilizer foot on each side of the front stabilizer mount (1) by inserting and partially tightening one M8 x 30-
mm bolt and washer on each foot (2).
5. Fully seat each stabilizer foot to the front stabilizer mount, and tighten the bolts from step 4.
6. Lower the rack so that the full weight of the rack rests on the rear leveling feet and the front stabilizer feet.
WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:
• The front and rear leveling feet are extended to the floor.
• The full weight of the rack rests on the rear leveling feet and front stabilizer feet.
Heavy Duty Stabilizer kit 71
