Power Supply Loading Guidelines
The supported configuration of the server requires a minimum of one power supply installed in
either slot P0 or slot P1. You can install a second, optional hot-swappable power supply to provide
1+1 capability. The left side (viewed from the rear of the chassis) hot-swappable power supply is
identified as P0, and the second hot-swappable power supply is identified as P1 (Figure 3).
CAUTION: When a second power supply is not used, the empty power supply slot must remain
covered with the supplied metal filler panel. Failure to observe this caution can result in damage
due to overheating.
Install the hot-swappable power supply into the server before attaching the new power cord. Failure
to observe this caution can result in damage to the server.
Installing a Hot-Swappable Power Supply
To install a hot-swappable power supply on the front of the server, follow these steps:
1. Remove the metal filler panel if necessary.
2. Support the power supply with both hands, and slide it into the empty slot until it clicks into
place (Figure 3).
IMPORTANT: Ensure the power supply is flush with the adjacent power supply or metal filler
panel.
14 Installing the System
