1 Installing the System
This chapter covers the procedures for installing the HP Integrity rx3600 server.
This chapter addresses the following topics
• “Safety Information” (page 9)
• “Installation Sequence and Checklist” (page 10)
• “Unpacking and Inspecting the Server” (page 10)
• “Installing Additional Components” (page 12)
• “Installing the Server into a Rack or Pedestal Mount” (page 32)
• “Connecting the Cables” (page 33)
• “Console Setup” (page 36)
• “Accessing the Host Console” (page 45)
• “Powering On and Powering Off the Server” (page 48)
• “Core I/O Card Configuration” (page 49)
• “Installation Troubleshooting” (page 71)
• “Enabling the Trusted Platform Module” (page 74)
Safety Information
Use care to prevent injury and equipment damage when performing removal and replacement
procedures. Voltages can be present within the server even when it is powered off. Many assemblies
are sensitive to damage by electrostatic discharge (ESD).
Follow the safety precautions listed below to ensure safe handling of components, to prevent injury,
and to prevent damage to the server:
• When removing or installing any server component, follow the instructions provided in this
guide.
• If installing a hot-swappable or hot-pluggable component when power is applied (fans are
running), reinstall the server cover immediately to prevent overheating.
• If installing a hot-pluggable component, complete the required software intervention prior to
removing the component.
• If installing an assembly that is neither hot-swappable nor hot-pluggable, disconnect the power
cable from the external server power receptacle.
WARNING! Ensure that the system is powered off and all power sources are disconnected
from the server prior to removing or installing server hardware unless you are removing or
installing a hot-swappable or hot-pluggable component.
Voltages are present at various locations within the server whenever an AC power source is
connected. This voltage is present even when the main power switch is turned off.
Failure to observe this warning can result in personal injury or damage to equipment.
• Do not wear loose clothing that can snag or catch on the server or on other items.
• Do not wear clothing subject to static charge buildup, such as wool or synthetic materials.
Safety Information 9
