HP J8697A Advanced Traffic Management Guide

5-54
Quality of Service: Managing Bandwidth More Effectively
Globally-Configured QoS
Figure 5-21. Adding, Displaying, Removing, and Changing QoS Protocol Classifiers
HP Switch(config)# qos protocol ip priority 0
HP Switch(config)# qos protocol appletalk priority 7
HP Switch(config)# qos protocol arp priority 5
HP Switch(config)# show qos protocol-priority
Protocol priorities
Protocol Priority
-------- --------
IP 0
IPX No-override
ARP 5
AppleTalk 7
SNA No-override
Net BEUI No-override
HP Switch(config)# no qos protocol ip
HP Switch(config)# qos protocol arp priority 4
HP Switch(config)# show qos protocol-priority
Protocol priorities
Protocol Priority
-------- --------
IP No-override
IPX No-override
ARP 4
AppleTalk 7
SNA No-override
Net BEUI No-override
Configures IP, Appletalk, and
ARP as QoS classifiers.
Removes IP as QoS classifier.
Changes the priority of the ARP
QoS classifier.
Displays the results of these
changes.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
