HP J8697A Advanced Traffic Management Guide

1-14
Static Virtual LANs (VLANs)
VLAN Operating Rules
Figure 1-7. Untagged VLAN Operation
■ Tagged Packet Forwarding: If a port is a tagged member of the same
VLAN as an inbound, tagged packet received on that port, then the switch
forwards the packet to an outbound port on that VLAN. (To enable the
forwarding of tagged packets, any VLAN to which the port belongs as a
Yes
Port “X” receives
an inbound,
untagged Packet.
Is the
port an untagged
member of any
VLANs?
No
Does the
packet’s protocol
match the protocol of
an untagged VLAN
membership on
the port?
Drop the
packet.
No
Yes
Forward the
packet on that
protocol VLAN.
Is the
port a member
of an untagged,
port-based
VLAN?
No
Drop the
packet.
Yes
Forward the
packet on the
port-based VLAN.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
