HP J8697A Advanced Traffic Management Guide

1-33
Static Virtual LANs (VLANs)
Configuring VLANs
Figure 1-22. Example of “Show VLAN” for a Specific Static VLAN
Figure 1-23. Example of “Show VLAN” for a Specific Dynamic VLAN
HP Switch(config)# show vlans 22
Status and Counters - VLAN Information - VLAN 22
VLAN ID : 22
Name : VLAN22
Status : Port-based
Voice : Yes
Jumbo : No
Port Information Mode Unknown VLAN Status
---------------- -------- ------------ ----------
12 Untagged Learn Up
13 Untagged Learn Up
14 Untagged Learn Up
15 Untagged Learn Down
16 Untagged Learn Up
17 Untagged Learn Up
18 Untagged Learn Up
Show VLAN lists this
data when GVRP is
enabled and at least
one port on the switch
has dynamically
joined the designated
VLAN.
HP Switch(config)# show vlans 22
Status and Counters - VLAN Information - VLAN 22
VLAN ID : 33
Name : GVRP_33
Status : Dynamic
Voice : No
Jumbo : No
Port Information Mode Unknown VLAN Status
---------------- -------- ------------ ----------
6 Auto Learn Up
