HP J8697A Advanced Traffic Management Guide

1-38
Static Virtual LANs (VLANs)
Configuring VLANs
Figure 1-28. Example of Reassigning Primary VLAN and Changing the VLAN Name
HP Switch(config)# primary-vlan 22
HP Switch(config)# vlan 22 name 22-Primary
HP Switch(config)# show vlans
Status and Counters - VLAN Information
Maximum VLANs to support : 8
Primary VLAN : 22-Primary
Management VLAN :
VLAN ID Name Status Voice Jumbo
------- -------------------- ------------ ----- -----
1 DEFAULT_VLAN Static No No
22 22-Primary Static No No
Renames VLAN 22 to
“22-Primary”.
Reassigns the
Primary VLAN to
VLAN 22.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
