B-4
Monitoring and Analyzing Switch Operation
Status and Counters Data
Status and Counters Data
This section describes the status and counters screens available through the
switch console interface and/or the web browser interface.
Note You can access all console screens from the web browser interface via Telnet
to the console. Telnet access to the switch is available in the Device View
window under the Configuration tab.
Status or Counters Type Interface Purpose Page
Menu Access to Status and
Counters
Menu Access menu interface for status and counter data. B-5
General System Information Menu, CLI Lists switch-level operating information. B-6
Management Address
Information
Menu, CLI Lists the MAC address, IP address, and IPX network number for
each VLAN or, if no VLANs are configured, for the switch.
B-7
Module Information Menu, CLI Lists the module type and description for each slot in which a
module is installed.
B-8
Port Status Menu, CLI,
Web
Displays the operational status of each port. B-9
Port and Trunk Statistics
and Flow Control Status
Menu, CLI,
Web
Summarizes port activity and lists per-port flow control status. B-10
VLAN Address Table Menu, CLI Lists the MAC addresses of nodes the switch has detected on
specific VLANs, with the corresponding switch port.
B-13
Port Address Table Menu, CLI Lists the MAC addresses that the switch has learned from the
selected port.
B-13
STP Information Menu, CLI Lists Spanning Tree Protocol data for the switch and for individual
ports. If VLANs are configured, reports on a per-VLAN basis.
B-17
IGMP Status Menu, CLI Lists IGMP groups, reports, queries, and port on which querier is
located.
B-19
VLAN Information Menu, CLI For each VLAN configured in the switch, lists 802.1Q VLAN ID and
up/down status.
B-20
Port Status Overview and
Port Counters
Web Shows port utilization and counters, and the Alert Log.B-22
