B-23
Monitoring and Analyzing Switch Operation
Port and Static Trunk Monitoring Features
Port and Static Trunk Monitoring
Features
Port Monitoring Features
You can designate a port for monitoring inbound (ingress) and outbound
(egress) traffic of other ports and of static trunks on the switch. The switch
monitors the network activity by copying all inbound and outbound traffic on
the specified interfaces to the designated monitoring port, to which a network
analyzer can be attached.
The instructions below apply to all of the switches covered in this manual.
Note Port trunks cannot be used as a monitoring port.
It is possible, when monitoring multiple interfaces in networks with high
traffic levels, to copy more traffic to a monitor port than the link can support.
In this case, some packets may not be copied to the monitor port.
Feature Default Menu CLI Web
display monitoring
configuration
disabled page B-24 page B-26 page B-28
configure the monitor port(s) ports: none page B-24 page B-27 page B-28
selecting or removing ports none selected page B-24 page B-27 page B-28

HP ProCurve 2510-24 Specifications

General

Model	HP ProCurve 2510-24
Switching Capacity	8.8 Gbps
Layer	Layer 2
Form Factor	Rack-mountable
MAC Address Table Size	8000 entries
Jumbo Frame Support	Yes
Power	AC 120/230 V (50/60 Hz)
Management	Web, SNMP, CLI
Features	VLAN support, QoS
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Temperature	0 to 40 °C
Operating Humidity	15% to 95% (non-condensing)
Dimensions	44.25 x 17.3 x 4.45 cm
