B-22
Monitoring and Analyzing Switch Operation
Status and Counters Data
Web Browser Interface Status Information
The “home” screen for the web browser interface is the Status Overview
screen, as shown below. As the title implies, it provides an overview of the
status of the switch, including summary graphs indicating the network utili-
zation on each of the switch ports, symbolic port status indicators, and the
Alert Log, which informs you of any problems that may have occurred on the
switch.
For more information on this screen, see chapter 5, ‘Using the Web Browser
Interface’.
Figure B-18. Example of a Web Browser Interface Status Overview Screen
Port
Utilization
Graphs
Port Status
Indicators
Alert Log

HP ProCurve 2510-24 Specifications

General

Model	HP ProCurve 2510-24
Switching Capacity	8.8 Gbps
Layer	Layer 2
Form Factor	Rack-mountable
MAC Address Table Size	8000 entries
Jumbo Frame Support	Yes
Power	AC 120/230 V (50/60 Hz)
Management	Web, SNMP, CLI
Features	VLAN support, QoS
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Temperature	0 to 40 °C
Operating Humidity	15% to 95% (non-condensing)
Dimensions	44.25 x 17.3 x 4.45 cm
