D-5

MAC Address Management

Determining MAC Addresses in the Switch

Figure D-2. Example of Port MAC Address Assignments

ifPhysAddress.226

& 237MAC Addresses for

non-default VLANs.

ifPhysAddress.1 - 6:Ports A1 - A6 in Slot 1

(Addresses 7 - 24 in slot 1 and 25 - 48 in slot 2 are

unused.)

ifPhysAddress.49 - 51:Ports C1 - C3 in Slot 3

(Addresses 52 - 72 in slot 3 are unused.)

ifPhysAddress.205Base MAC Address (MAC

Address for default VLAN;

VID = 1)
