10-11

Monitoring and Analyzing Switch Operation

Status and Counters Data

Monitoring and Analyzing

Switch Operation

Viewing the Switch’s MAC Address Tables

These features help you to view:

■ The MAC addresses that the switch has learned from network devices

attached to the switch

■ The port on which each MAC address was learned

Feature Default Menu CLI Web

viewing MAC addresses on all

ports

n/a page 10-12 page 10-14 —

viewing MAC addresses on a

specific port

n/a page 10-13 page 10-14 —

viewing MAC addresses on a

specific VLAN

n/a — page 10-14 —

searching for a MAC address n/a page 10-13 page 10-14 —
