4-3

Using the HP Web Browser Interface

General Features

Using the HP Web Browser

Interface

General Features

The Series 2500 switches include these web browser interface features:

Switch Configuration:

• Ports

• VLANs and Primary VLAN

• Fault detection

• Port monitoring (mirroring)

• System information

• Enable/Disable Multicast Filtering (IGMP) and Spanning Tree

• IP

• Stacking

• Support and management URLs

Switch Security:

• Passwords

• Authorized IP Managers

• Port security and Intrusion Log

Switch Diagnostics:

• Ping/Link Test

• Device reset

• Configuration report

Switch status

• Port utilization

• Port counters

• Port status

• Alert log

Switch system information listing
