10-26
Monitoring and Analyzing Switch Operation
Port Monitoring Features
Monitoring and Analyzing
Switch Operation
Figure 10-21.Examples of Removing Ports and VLANs as Monitoring Sources
Web: Configuring Port Monitoring
To enable port monitoring:
1. Click on the Configuration tab.
2. Click on [Monitor Port].
3. Do either of the following:
• To monitor a VLAN:
i. Click on the radio button for Monitor 1 VLAN.
ii. Select the VLAN to monitor.
• To monitor one or more ports.
i. Click on the radio button for Monitor Selected Ports.
ii. Select the port(s) to monitor.
4. Click on [Apply Changes].
To remove port monitoring:
1. Click on the Monitoring Off radio button.
2. Click on [Apply Changes].
For web-based Help on how to use the web browser interface screen, click on
the [?] button provided on the web browser screen.
From the global config level, removes
ports or VLAN as monitoring sources.
From the interface or VLAN context level,
removes the ports or VLAN as monitoring
sources.
