Server cabling 117
RILOE II cabling
The 30-pin Remote Insight cable ships with the RILOE II cable kit.
CAUTION: When routing cables, always be sure that the cables
are not in a position where they can be pinched or crimped.
IMPORTANT: Install the RILOE II board into slot 7 for ease of
cabling.
Hot-plug SCSI drive cabling
CAUTION: When routing cables, always be sure that the cables
are not in a position where they can be pinched or crimped.
The following are the standard SCSI cabling configurations for this server:
• Single-channel (simplex mode) SCSI cabling to the SCSI ports
• Dual-channel (duplex mode) SCSI cabling to the SCSI ports
• Standard SCSI cabling to an expansion board
NOTE: The server ships with the required cables.
