Server operations 43
3. Remove the access panel ("Removing the access panel" on page 40).
4. Remove all expansion boards and expansion slot covers.
5. Remove the PCI-X Hot Plug basket, if applicable.
6. Disconnect the hot-plug board cable from the PCI-X Hot Plug mezzanine
board, if applicable.
7. Remove all system fans ("Replacing hot-plug fans" on page 41
).
8. Remove all power supplies ("Redundant hot-plug power supply" on page
70
).
9. Loosen the thumbscrews, and lift the system cage from the server.
NOTE: The T-15 Torx screwdriver can be used to loosen the
thumbscrews. The T-15 Torx screwdriver is shipped with the server and
can be located on the rear panel ("Rear panel components" on page
16
).
Accessing the QuickFind diagnostic display
1. Extend the server from the rack, if applicable ("Extending the server from the
rack" on page 38
).
2. Remove the access panel ("Removing the access panel" on page 40
).
