Server component identification 21
Item Description Item Description
5 System maintenance
switch
16 Fan 6
6 System battery 17 Fan 5
7 Connectors for one of
the following:
• PCI-X Hot Plug
mezzanine option
• PCI Express x4
mezzanine option
• PCI Express x8
mezzanine option
18 Boot device selector
switch (default = FLP
TOP)
8 PCI-X non-hot-plug
slot 3, 64-bit/133-MHz
19 SCSI port A
9 PCI-X, non-hot-plug
slot 4, 64-bit/133-MHz
20 SCSI simplex/duplex
switch (default =
duplex)
10 PCI-X, non-hot-plug
slot 5, 64-bit/133-MHz
21 QuickFind diagnostic
display
11 PCI-X, non-hot-plug
slot 6, 64-bit/100-MHz
22 SCSI port B
System maintenance switch
The system maintenance switch (SW1) is an eight-position switch that is used for
system configuration. The default position for all eight positions is Off.
Position Description Function
S1 iLO Security Off = iLO security is enabled
On = iLO security is disabled
S2 Configuration
lock
Off = System configuration can
be changed
On = System configuration is
locked
S3 Reserved Reserved
