Server component identification 23
Switch setting Description
FLP TOP
(default)
Diskette drive in top bay is bootable
Primary optical drive in bottom bay is bootable
FLP BOT Primary optical drive in top bay is bootable
Diskette drive in bottom bay is bootable
QuickFind diagnostic display LEDs
The front panel health LEDs indicate only the current hardware status. In some
situations, HP SIM might report server status differently than the health LEDs
because the software tracks more system attributes.
The amber QuickFind diagnostic display LEDs are located on the media board.
In normal operations, all of the LEDs are off unless one of the components fails.
