HP ProLiant DL580 Generation 3

To Next Page

To Previous Page

Server component identification 19

Fail LED 1

(amber)

Power LED 2

(green)

Description

Off Off No AC power to any power

supply

Flashing Off Power supply failure (over

current)

On Off No AC power to this power

supply

Off Flashing • AC power present

• Standby mode

Off On Normal
