94 HP ProLiant DL580 Generation 3 Server User Guide
For information about iLO technology, refer to "Integrated Lights-Out
Technology (on page 132
)."
To install the RILOE II board:
IMPORTANT: Install the RILOE II board into slot 7 for ease of
cabling.
1. Power down the server ("Powering down the server" on page 37).
2. Remove the access panel ("Removing the access panel" on page 40
).
3. Install the RILOE II board into slot 7.
4. Connect the RILOE II cable ("RILOE II cabling" on page 117
) to the 30-pin
connector on the system board.
5. Connect the RILOE II cable to the RILOE II board.
