Onboard Devices Allows you to set resources for or disable Legacy devices.
Select the Legacy device's IRQ, DMA, and I/O Range. The settings may not take effect for all
operating systems. To hide a device from the operating system, see Security > Device Security.
Bus Options Allows you to enable or disable:
●
PCI SERR# Generation. Default is enabled.
●
PCI VGA Palette Snooping, which sets the VGA palette snooping bit in PCI configuration
space; only needed when more than one graphics controller is installed. Default is disabled.
Device Options Allows you to set:
●
USB EHCI Port Debug (enable/disable). Allows you to enable and disable the EHCI debug
port. The EHCI Debug Port is an optional capability of EHCI controllers.
●
Num Lock State at Power-On (off/on). Default is off.
●
Internal Speaker (does not affect external speakers). Default is enabled.
●
Multi-Processor (enable/disable). Use this option to disable multi-processor support under the
OS. Default is enabled.
●
USB Charging Port (enable/disable). Default is enabled.
●
USB 3.0 BIOS Driver Support (enabled/disabled). Default is disabled.
●
Hyper threading (enable/disable). Use this option to disable processor hyper-threading.
VGA Configuration Displayed only if there is an add-in video card in the system. Allows you to specify which VGA
controller will be the “boot” or primary VGA controller.
Option ROM Launch
Policy
(Windows 8 only). Windows 8 installs as a UEFI operating system (as opposed to ‘legacy’), and
ships with the ‘Legacy Support’ setting off in the BIOS. When ‘Legacy Support’ is off, the Option
ROM Launch Policies are set to ‘UEFI Only’. These policies control whether the Legacy Option ROM
or the UEFI driver is loaded for the following features:
●
PXE Option ROMs (UEFI Only/Do Not Launch). Specifies whether the legacy option ROM or
the UEFI driver in the BIOS is used to provide PXE services.
●
Storage Option ROMs (UEFI Only/Do Not Launch). Specifies whether the legacy option ROM
or the UEFI driver in the BIOS is used to provide RAID setup and support.
●
Video Option ROMs (UEFI Only/Do Not Launch). Specifies whether the legacy VBIOS or the
UEFI driver in the BIOS is used to provide graphics setup and support.
●
NetClone Option ROMs (Legacy Only/Do Not Launch). Only available on models with the
NetClone operating system.
PCIe Family
Controller
Provides information about the PCIe controller, including:
●
Driver Name/Version/Release Date
●
Device Name
●
PCI Slot
●
MAC Address
Computer Setup (F10) Utilities
93

HP ProOne 400 G1 Specifications

General

Full HD	No
Panel type	TN
LED backlight	Yes
Display diagonal	21.5 \
Display resolution	- pixels
Native aspect ratio	-
Tcase	72 °C
Bus type	DMI
Processor cache	3 MB
Processor cores	2
Processor model	i3-4130T
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-4100 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	4
Processor codename	Haswell
Number of QPI links	0
Processor frequency	2.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	32-bit, 64-bit
PCI Express configurations	2x8
Thermal Design Power (TDP)	35 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Product type	All-in-One PC
Motherboard chipset	Intel® H81
Internal memory	4 GB
Memory slots type	SO-DIMM
Memory clock speed	1600 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Intel segment tagging	Enterprise, Professional
Storage drive interface	Serial ATA
On-board graphics card ID	0x41E
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Wi-Fi standards	Not supported
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating system installed	Windows 8.1 Pro
Operating system architecture	64-bit
Scalability	1S
Processor ARK ID	77481
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0
Thermal solution specification	PCG 2013A
Intel Small Business Advantage (SBA) version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Product color	Black
Country of origin	China
Total megapixels	- MP
AC adapter power	120 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Package width	7420 mm
Depth (with stand)	59.4 mm
Width (with stand)	557.9 mm
Height (with stand)	362.9 mm
Weight (with stand)	5070 g
