Speakers
Speakers are located at the bottom of the computer. Two separate speakers are each secured by two
Torx screws.
To remove the speakers:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 27).
2. Remove the rear cover (see
Rear cover on page 30).
3. Remove four Torx screw that secure the speakers to the computer (1).
4. Remove the speaker wires from the clips built into the computer (2).
Speakers
45
