Bottom stand
The bottom stand is secured to the bottom of the computer by six Torx screws.
To remove the bottom stand:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 27).
2. Remove the rear cover (see
Rear cover on page 30).
3. Remove the three screws that secure the left side of the stand to computer.
48 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis
