Never cover the ventilation slots on the monitor with any type of material.
Install or enable power management functions of the operating system or other software, including
sleep states.
Routine care
General cleaning safety precautions
1. Never use solvents or flammable solutions to clean the computer.
2. Never immerse any parts in water or cleaning solutions; apply any liquids to a clean cloth and
then use the cloth on the component.
3. Always unplug the computer when cleaning with liquids or damp cloths.
4. Always unplug the computer before cleaning the keyboard, mouse, or air vents.
5. Disconnect the keyboard before cleaning it.
6. Wear safety glasses equipped with side shields when cleaning the keyboard.
Cleaning the Computer Case
Follow all safety precautions in General cleaning safety precautions on page 22 before cleaning the
computer.
To clean the computer case, follow the procedures described below:
To remove light stains or dirt, use plain water with a clean, lint-free cloth or swab.
For stronger stains, use a mild dishwashing liquid diluted with water. Rinse well by wiping it with
a cloth or swab dampened with clear water.
For stubborn stains, use isopropyl (rubbing) alcohol. No rinsing is needed as the alcohol will
evaporate quickly and not leave a residue.
After cleaning, always wipe the unit with a clean, lint-free cloth.
Occasionally clean the air vents on the computer. Lint and other foreign matter can block the vents
and limit the airflow.
Cleaning the keyboard
Follow all safety precautions in General cleaning safety precautions on page 22 before cleaning the
keyboard.
To clean the tops of the keys or the keyboard body, follow the procedures described in
Cleaning the
Computer Case on page 22.
When cleaning debris from under the keys, review all rules in
General cleaning safety precautions
on page 22 before following these procedures:
22 Chapter 4 Routine care, SATA drive guidelines, and disassembly preparation

Table of Contents

Other manuals for HP ProOne 400 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProOne 400 G1 and is the answer not in the manual?

HP ProOne 400 G1 Specifications

General IconGeneral
Full HDNo
Panel typeTN
LED backlightYes
Display diagonal21.5 \
Display resolution- pixels
Native aspect ratio-
Tcase72 °C
Bus typeDMI
Processor cache3 MB
Processor cores2
Processor modeli3-4130T
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-4100 Desktop series
Processor socketLGA 1150 (Socket H3)
Processor threads4
Processor codenameHaswell
Number of QPI links0
Processor frequency2.9 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor operating modes32-bit, 64-bit
PCI Express configurations2x8
Thermal Design Power (TDP)35 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Product typeAll-in-One PC
Motherboard chipsetIntel® H81
Internal memory4 GB
Memory slots typeSO-DIMM
Memory clock speed1600 MHz
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Intel segment taggingEnterprise, Professional
Storage drive interfaceSerial ATA
On-board graphics card ID0x41E
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4400
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card base frequency200 MHz
On-board graphics card DirectX version11.1
On-board graphics card dynamic frequency (max)1150 MHz
Number of displays supported (on-board graphics)3
Wi-Fi standardsNot supported
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating system installedWindows 8.1 Pro
Operating system architecture64-bit
Scalability1S
Processor ARK ID77481
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0
Thermal solution specificationPCG 2013A
Intel Small Business Advantage (SBA) version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Product colorBlack
Country of originChina
Total megapixels- MP
AC adapter power120 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)15 - 80 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Package width7420 mm
Depth (with stand)59.4 mm
Width (with stand)557.9 mm
Height (with stand)362.9 mm
Weight (with stand)5070 g
