Component identification 11
Interface adapters
Interface adapters that support Virtual Media have two LEDs on the front of the RJ-45 connector.
Item Description
1
When lit, this LED indicates that the interface adapter has power from
the server.
2
When lit, this LED indicates that there is an active console session with
the interface adapter.
When flashing, this LED indicates that the interface adapter firmware is
being upgraded.
USB 2.0 interface adapter with Virtual Media
Item Description
1
Video connector
