Chapter 1 17
Product Information
Chapter Overview
Standard I/O • Two Serial (RS-232) ports
• Two USB (Universal Serial Bus) ports
• One Parallel (IEEE 1284) port
• Four Audio ports (Line In, Line Out, Microphone In, and Headphones Out)
I/O Expansion
Capabilities
Four PCI (Peripheral Connect Interface) slots:
• Two 64-bit PCI-2X slots at 5V, 33 MHz
• Two 32-bit PCI-1X slots at 5V, 33MHz
Monitors
Currently
Supported
• 21-inch, 1280
×
1024 (stereo capable) color, 75 Hz, VESA
• 21-inch, 1600
×
1200 color, 75 Hz, VESA
• 19-inch, 1280
×
1024 color, 75 Hz, VESA
Graphics • Integrated HP V
ISUALIZE
-fxe graphics chip on the system board
• HP V
ISUALIZE
-fxe graphics card (optional)
Keyboard USB (Universal Serial Bus) HP keyboard
Mouse USB (Universal Serial Bus) HP three-button mouse (standard), or
USB HP scroll-wheel mouse (optional)
Table 1-1. Key Features of the B2000 Workstation
Feature Description
