Chapter 2 39
Configuration
System Hardware Configurations
I/O Cards
The B2000 workstation’s system board has four Peripheral Connect Interface (PCI) slots
for option I/O cards. Slots 1 and 2 are full-size (PCI-2X) slots. Slots 3 and 4 are half-size
(PCI-1X) slots. See Figure 2-3 for a brief description of slot capabilities.
Figure 2-3. PCI Card Slot Numbering and Capabilities
To remove and replace or install I/O cards, see the section titled “I/O Cards” on page 110.
NOTE
If you are installing an additional HP V
ISUALIZE
-fxe graphics card, after you
connect the monitor to the additional graphics card, you must change the
graphics path for that monitor. To do this, see the section “Displaying and
Setting the Monitor Type” on page 150.
64-bits, 5V, 33MHz
64-bits, 5V, 33MHz
32-bits, 5V, 33MHz
32-bits, 5V, 33MHz
Slot 1
Slot 2
Slot 4
Slot 3
