DescriptionItem
Capacity
• Total: Displays the logical volume capacity.
• Used: Displays the V-VOL used capacity.
The Total value displayed might be larger than the Used value due to following
reasons:
◦ Used displays the used capacity of the V-VOL that is rounded up on each
page.
◦ If the emulation type is 3390-A, the used capacity of V-VOL includes the
capacity of the control cylinders (7 Cyl is required per 1,113 Cyl).
If the logical volume is not the volume other than V-VOL, a hyphen (-) is
displayed.
• Used(%): Displays the V-VOL usage level. If the logical volume is not the
volume other than V-VOL, a hyphen (-) is displayed.
Used Capacity
• Tier1: Displays the used capacity of tier 1. If the logical volume is not the
volume other than V-VOL, a hyphen (-) is displayed.
• Tier2: Displays the used capacity of tier 2. If the logical volume is not the
volume other than V-VOL, or if tier 2 does not exist, a hyphen (-) is displayed.
• Tier3: Displays the used capacity of tier 3. If the logical volume is not the
volume other than V-VOL, or if tier 3 does not exist, a hyphen (-) is displayed.
Displays the type for each logical volume.Provisioning Type
Basic: Internal volume.
External: External volume.
THP: V-VOL of Thin Provisioning.
Snapshot: Fast Snap volume.
Cache logical partition number, displayed as ID:CLPR.CLPR
Displays the tiering policy name and ID.Tiering Policy
All(0): Policy specified when all tiers in the pool are used.
Level1(1) to Level31(31): Policy selected from Level1 to Level31, set to the V-VOL.
Hyphen (-): The logical volume is not the Smart Tiers or Smart Tiers Z V-VOL.
Displays the new page assignment tier of the tiering policy. See “New page
assignment tier” (page 105).
New Page Assignment Tier
Hyphen (-): The logical volume is not the Smart Tiers or Smart Tiers Z V-VOL.
Displays whether tier relocation is set to Enable or Disable. If the logical volume
is not to the V-VOL of Smart Tiers or Smart Tiers Z, a hyphen (-) is displayed.
Tier Relocation
Displays the attribute of the LDEV.Attribute
Command Device: Command device.
Remote Command Device: Remote command device.
Hyphen (-): Volume in which the attribute is not defined.
Displays the access attribute of the LDEV.Access Attribute
1
Displays the information about parity group encryption.Encryption
1
Enabled: The encryption of the parity group which contains LDEV is enabled.
Disabled: The encryption of the parity group which contains LDEV is disabled.
If LDEV is a V-VOL for Thin Provisioning, external volume, or migration volume,
a hyphen (-) is displayed.
Displays the total number of relevant paths and alternative paths.Number of Paths
376 LUN Manager GUI reference
