HP Z800

4.
Lift the drive release latch at the green label touch point (1), and gently slide the filler tray out of
the chassis (2), as shown in the following figure.
TIP: Store excess power cables in the filler tray. Remove the cables before removing the tray
from the chassis.
Figure 5-22 Removing a filler tray
98 Chapter 5 Replacing components ENWW
