Front panel components
The following illustration shows the front panel components of a typical workstation configuration. Drive
configurations can vary.
Figure 1-3 Front panel
Table 1-2 Front panel components
*
Item Symbol Description Item Symbol Description
1
5.25-inch drive bays (3) 6
Headphone connector
2
optical disk drive eject button 7
Microphone connector
3
Workstation power button/power on light 8 IEEE-1394a connector
4
Hard drive activity light 9 Optical disk drive activity light
5
USB 2.0 connectors (3) 10 Optical disk drive
*
Refer to the Maintenance and Service Guide for the workstation for specific front panel connector information.
