HP Z800

Power supply currents
Table 1-6 Maximum current per rail
Voltage rail 850W maximum
continuous current
1110W maximum
continuous current
+12 V-CPU0 18.0A 18.0A
+12 V-CPU1 18.0A 18.0A
+12 V-MO 18.0A 18.0A
+12 V-M1 18.0A 18.0A
+12 V-B 18.0A 18.0A
+12 V-S 18.0A 18.0A
+12 V-D 18.0A 18.0A
+12 V-G/G1 18.0A 18.0A
+12 V-G2 N/A 18.0A
V12N 0.15A 0.15A
+5 V-SB 5.00A 9.0A
CAUTION: Do not exceed 70.0 amps (840 watts) of 12-volt (CPU0/CPU1/M0/M1/B/D/S/G)
power combination for the 850W power supply.
Do not exceed 92.5A amps (1110 watts) of 12-volt (CPU0/CPU1/M0/M1/B/D/S/G1/G2) power
combination for the 1110W power supply.
Do not exceed 104.2A amps (1250 watts) of 12-volt (CPU0/CPU1/M0/M1/B/D/S/G1/G2) power
combination for the 1250W power supply.
Do not exceed 850 watts (for the 850-W power supply), or 1110 watts (for the 1110-W power supply)
of total continuous output power.
ENWW
Specifications
11
