Page #66 background imageLoading...
Page #66 background image
Table 4-2 Security features overview
Feature Purpose How it is established
Removable Media Boot Control Prevents booting from removable media
drives
From the Computer Setup (F10)
Utility menu
Serial, Parallel, USB,
or Infrared Interface Control
Prevents transfer of data through the
integrated serial, parallel, USB, or infrared
interface
From the Computer Setup (F10)
Utility menu
Power-On Password Prevents use of the workstation until the
password is entered (applies to initial system
startup and restarts)
From the Computer Setup (F10)
Utility menu
Setup Password Prevents reconfiguration of the workstation
(use of the Setup utility) until the password is
entered
From the Computer Setup (F10)
Utility menu
Network Server Mode Provides unique security features for
workstations used as servers
From the Computer Setup (F10)
Utility menu
SATA hard disk drive security
HP workstations include the HP DriveLock facility for SATA hard disk drives to prevent unauthorized
access to data.
WARNING! Enabling DriveLock can render a SATA hard disk drive permanently inaccessible if the
master password is lost or forgotten. No method exists to recover the password or access the data.
DriveLock has been implemented as an extension to Computer Setup (F10) functions. It is only available
when hard disk drives that support the ATA security command set are detected. On HP workstations, it
is not available when the SATA emulation mode is RAID+AHCI or RAID.
DriveLock is for HP customers for whom data security is a paramount concern. For such customers, the
cost of a hard disk drive and the loss of the data stored on it is inconsequential when compared to the
damage that could result from unauthorized access to its contents.
To balance this level of security with the need to address the issue of a forgotten password, the HP
implementation of DriveLock employs a two-password security scheme. One password is intended to be
set and used by a system administrator, while the other is typically set and used by the user.
No "back door" can be used to unlock the drive if both passwords are lost. Therefore, DriveLock is
most safely used when the data contained on the hard disk drive is replicated on a corporate
information system or is regularly backed up.
If both DriveLock passwords are lost, the hard disk drive is rendered unusable. For users who do not fit
the previously defined customer profile, this might not be acceptable. For users who fit this profile, it
might be a tolerable risk, given the nature of the data stored on the hard disk drive.
54 Chapter 4 System management ENWW

Table of Contents

Other manuals for HP Z800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z800 and is the answer not in the manual?

HP Z800 Specifications

General IconGeneral
Processor cache8 MB
Processor modelE5560
Processor frequency2.8 GHz
Processor cache typeL2
Processor manufacturerIntel
Processor front side bus1333 MHz
Number of processors installed2
Audio systemIntegrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product typeWorkstation
Motherboard chipsetIntel® 5520
ECCYes
Maximum internal memory192 GB
HDD speed15000 RPM
HDD capacity446 GB
HDD interfaceSerial Attached SCSI (SAS)
Optical drive typeDVD Super Multi
Card reader integratedNo
I/O portsFront: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs1
USB 2.0 ports quantity9
Parallel ports quantity0
Power supply1110 W
Power consumption (typical)240 W
Non-operating altitude9100 m
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 90 %
Operating relative humidity (H-H)8 - 85 %
DisplayHP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays3 external 5.25\
Graphics card-
Keyboard typeHP PS/2 Standard Keyboard
Expansion slots1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing deviceHP USB Laser Scroll Mouse
Power requirements1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller typeSATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card featuresNo integrated Graphic Card
Maximum HDD capacity450 GB
Storage drive controllerIntegrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space146 GB
Operating system installedWindows Vista Business
Compatible operating systemsHP Installer Kit for Linux
Chassis typeMini Tower
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth526.5 mm
Width203.5 mm
Height445.1 mm
Weight19500 g
