Page #41 background imageLoading...
Page #41 background image
Restoring the operating system
CAUTION: Before you restore the operating system, back up your data.
When you run RestorePlus! from media, the process deletes all information on the primary hard drive,
including all partitions. If you run RestorePlus! from the recovery partition, only the root (C:) partition is
affected.
Using RestorePlus!
To restore with RestorePlus!:
1.
Boot the workstation from the RestorePlus! DVD. You must start from the RestorePlus! DVD for
device drivers and settings to be installed.
2.
Follow the prompts to restore the operating system.
Some application software might not be restored using this process. If software is not restored, install it
from the appropriate application DVD.
Using HPBR
To restore with the HPBR Initial Recovery Point media:
1.
Boot the workstation from the Initial Recovery Point media.
2.
Follow the prompts to restore the system to the state when the IRP was created.
Using the recovery partition
A system that shipped with Windows XP includes a recovery partition. You can boot the system from
that recovery partition.
From the recovery partition you can perform a system restore using the HPBR Initial Recovery Point, if it
was created. If it was not, you can use a RestorePlus! install.
To restore using the recovery partition:
1.
Boot the workstation.
2.
When prompted on the boot screen to enter the Recovery Manager, press F11.
TIP: The opportunity to press F11 during the boot process is small. It comes about the time the
F10 prompt appears.
NOTE: To ensure that the recovery processes reinstall on the correct hard drive, do not
disconnect the target drive during the recovery process.
3.
Follow the prompts to restore the system to factory-like condition.
Restoring Novell SLED
The SLED restore media is required to restore the Linux operating system.
ENWW
Restoring Novell SLED
29

Table of Contents

Other manuals for HP Z800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z800 and is the answer not in the manual?

HP Z800 Specifications

General IconGeneral
Processor cache8 MB
Processor modelE5560
Processor frequency2.8 GHz
Processor cache typeL2
Processor manufacturerIntel
Processor front side bus1333 MHz
Number of processors installed2
Audio systemIntegrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product typeWorkstation
Motherboard chipsetIntel® 5520
ECCYes
Maximum internal memory192 GB
HDD speed15000 RPM
HDD capacity446 GB
HDD interfaceSerial Attached SCSI (SAS)
Optical drive typeDVD Super Multi
Card reader integratedNo
I/O portsFront: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs1
USB 2.0 ports quantity9
Parallel ports quantity0
Power supply1110 W
Power consumption (typical)240 W
Non-operating altitude9100 m
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 90 %
Operating relative humidity (H-H)8 - 85 %
DisplayHP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays3 external 5.25\
Graphics card-
Keyboard typeHP PS/2 Standard Keyboard
Expansion slots1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing deviceHP USB Laser Scroll Mouse
Power requirements1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller typeSATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card featuresNo integrated Graphic Card
Maximum HDD capacity450 GB
Storage drive controllerIntegrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space146 GB
Operating system installedWindows Vista Business
Compatible operating systemsHP Installer Kit for Linux
Chassis typeMini Tower
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth526.5 mm
Width203.5 mm
Height445.1 mm
Weight19500 g
