Memory fans
This section describes how to remove and install the memory fans.
Removing the memory fans
1.
Disconnect power from the workstation (see
Predisassembly procedures on page 77).
2.
Remove the side access panel (see
Removing the side access panel on page 79).
3.
Remove the airflow guide (see
Removing the airflow guide on page 80).
4.
Grasp the sides of the memory fan assembly (1), and then use your index fingers to press the
memory fan assembly release tabs (2), as shown in the following figure.
Figure 5-85 Releasing the memory fan assembly
ENWW
Removing and installing components
155
