HP Z800 Service Manual

Table 4-1 Computer Setup (F10) Utility menu descriptions (continued)
Heading Option Description
Default Setup Provides these options:
●
Save Current Settings as Default—Saves the current settings as default settings for the next
operation.
●
Restore Factory Settings as Default—Restores the factory settings as the default settings for the
next operation.
Apply Defaults
and Exit
Restores the default settings defined in Default Setup.
Ignore Changes
and Exit
Exits workstation setup without applying or saving changes.
Save Changes
and Exit
Saves changes to system configuration and exits the workstation setup.
Storage Device
Configuration
Lists installed non-SCSI storage devices (except SATA devices) and provides options for obtaining
specific information about each device:
●
Hard Disk—Provides information about the hard disk drives in the workstation. It is available
in IDE Mode only.
●
CD-ROM—Provides information about the optical disk drives in the workstation. (IDE mode
only.)
●
Diskette Type (for legacy diskette drives only)—Identifies the highest capacity media type
accepted by the diskette drive. Options are 3.5" (1.44 MB), 5.25" (1.2 MB), and Not
Installed.
●
Default Values—Resets devices to their default configuration (SATA is the default).
◦
Multisector Transfers—Defines the transfer of data per interrupt. Options are 8, 16, and
Disable (16 is the default).
◦
Transfer Mode—Specifies the active data transfer mode. Options (subject to device
capabilities) are Max UDMA, PIO 0, Max PIO, Enhanced DMA, and Ultra DMA0.
(Max UDMA is the default).
◦
Translation Mode—Enables the BIOS to determine the translation mode used to
configure a formatted SATA or USB mass storage device. This prevents you from
needing to know how the mass storage device was formatted. Options are Automatic,
Bit Shift, LBA Assisted, Use (Cylinders, Heads, Sectors), and Off. Automatic is the
default.
Ordinarily, you should not change the translation mode selected by the BIOS. If the
selected translation mode is not compatible with the translation mode that was active
when the drive was partitioned and formatted, the data on the disk is inaccessible.
36 Chapter 4 System management ENWW

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
