HP Z800 Service Manual

Table 4-1 Computer Setup (F10) Utility menu descriptions (continued)
Heading Option Description
Chipset/
Memory
Enable/disable these options:
●
PCI SERR# Generation (Enable or Disable)—Controls PCI SERR# generation for ill-behaved
PCI add-in cards (that can generate SERR# spuriously).
●
PCI VGA Palette Snooping (Enable or Disable)—Controls PCI VGA Palette Snooping for
compatibility purposes.
●
Memory Mode Interleave—Sets interleave mode for dual socket workstations.
●
NUMA Split Mode (Enable or Disable)—Provides enhanced memory performance by
increasing memory operation speed. Enable this option for Windows, and disable it for
Linux. (This option is not available on all workstations or configurations.)
●
Enhanced Memory Performance (Enable or Disable)—Runs DIMMs at a higher frequency on
certain configurations and platforms.
Device Options Enables you to set the following device options:
●
Num Lock State at Power-On (On or Off)
●
S5 Wake-on-LAN (Enable or Disable)
●
Multiprocessor (Activates a single core.)
●
Unique Sleep State Blink Rates (Enable or Disable)
●
Internal speaker
●
Monitor Tracking (Enable or Disable)
●
NIC PXE Option ROM
1
Download (Enable or Disable)
●
SAS Option ROM
1
Download (Enable or Disable) (Not available on some workstations.)
●
SATA RAID Option ROM
1
Download (Enable or Disable)
HP Z800 Workstation PCI slots
Slot 1 - PCIe2
x8(4)
Slot 1 option ROM download (Enable or Disable)
Slot 2 - PCIe2
x16
Slot 2 option ROM download (Enable or Disable)
Slot 3 - PCIe
x8(4)
Slot 3 option ROM download (Enable or Disable)
Slot 4 - PCIe2
x16(8)
Slot 4 option ROM download (Enable or Disable)
Slot 5 - PCIe2
x16
Slot 5 option ROM download (Enable or Disable)
Slot 6 - PCI
32/33
Slot 6 option ROM download (Enable or Disable), and latency timer and speed
Slot 7 - PCIe2
x16(8)
Slot 7 option ROM download (Enable or Disable), and latency timer and speed
HP Z600 PCI slots
42 Chapter 4 System management ENWW

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
