HPE 5510 HI Series User Manual

1
Preparing for installation
Table 1 HPE 5510 HI switches, power supplies, and interface cards
Product code
HPE description
Alias
HPE 5510 HI switches
JH145A
HPE 5510 24G 4SFP+ HI 1-slot Switch
HPE 5510 24G 4SFP+ HI
JH146A
HPE 5510 48G 4SFP+ HI 1-slot Switch
HPE 5510 48G 4SFP+ HI
JH147A
HPE 5510 24G PoE+ 4SFP+ HI 1-slot Switch
HPE 5510 24G PoE+ 4SFP+ HI
JH148A
HPE 5510 48G PoE+ 4SFP+ HI 1-slot Switch
HPE 5510 48G PoE+ 4SFP+ HI
JH149A
HPE 5510 24G SFP 4SFP+ HI 1-slot Switch
HPE 5510 24G SFP 4SFP+ HI
Power supplies
JD362A
HP A5800/A5500 150W AC Power Supply
PSR150-A1
JD366A
HP A5800/A5500 150W DC Power Supply
PSR150-D1
JG545A
HP X362 1110W AC PoE Power Supply
PSR720-56A
JG544A
HP X362 720W AC PoE Power Supply
PSR1110-56A
Interface cards
JH155A
HPE 5510 2-port QSFP+ Module
LSWM2QP2P
JH156A
HPE 5130/5510 10GBASE-T 2-port Module
LSWM2XGT2PM
JH157A
HPE 5130/5510 10GbE SFP+ 2-port Module
LSWM2SP2PM
For regulatory identification purposes, the HPE 5510 HI switches are assigned regulatory model numbers
(RMNs), which are listed in the following table. These regulatory numbers should not be confused with
the marketing names HPE 5510 HI, or the product codes.
Product code
RMN
HPE description
JH145A
BJNGA-AD0039
HPE 5510 24G 4SFP+ HI 1-slot Switch
JH146A
BJNGA-AD0040
HPE 5510 48G 4SFP+ HI 1-slot Switch
JH147A
BJNGA-AD0041
HPE 5510 24G PoE+ 4SFP+ HI 1-slot Switch
JH148A
BJNGA-AD0042
HPE 5510 48G PoE+ 4SFP+ HI 1-slot Switch
JH149A
BJNGA-AD0051
HPE 5510 24G SFP 4SFP+ HI 1-slot Switch
Safety recommendations
To avoid any equipment damage or bodily injury caused by improper use, read the following safety
recommendations before installation. Note that the recommendations do not cover every possible
hazardous condition.

HPE 5510 HI Series Specifications

General

Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Uplinks	4x 10G SFP+
Layer Support	Layer 3
Stacking	Up to 9 switches
Routing Protocol	OSPF, BGP, RIP
VLANs	4094
Operating Humidity	10% to 90% (non-condensing)
Switching Capacity	Up to 336 Gbps
Ports	24 or 48 x 10/100/1000 ports, plus optional 10GbE uplinks
PoE Support	IEEE 802.3af PoE and IEEE 802.3at PoE+ (on PoE models)
Dimensions	440 x 430 x 44 mm
