10/100/1000Base-T autosensing Ethernet port LED
The switch provides a status LED for each 10/100/1000Base-T autosensing Ethernet port. The status LED
in conjunction with the port mode LED indicates the operating state of the 10/100/1000Base-T
autosensing Ethernet port.
Table 27 10/100/1000Base-T autosensing Ethernet port LED description
Port mode LED (Mode)
status
10/100/1000Base-T
autosensing Ethernet
port LED status
A link is present on the port and the port is operating
at 1000 Mbps.
The port is sending or receiving data at 1000 Mbps
The port is operating at 10/100 Mbps.
The port is sending or receiving data at 10/100
Mbps
POST has failed on the port.
No link is present on the port.
Flashing green (1 Hz) (PoE
mode, available only for
HPE 5510 24G PoE+
4SFP+ HI and HPE 5510
48G PoE+ 4SFP+ HI
switches)
PoE power supply is normal.
The device attached to the port requires power
higher than the maximum or currently available PoE
output power on the port.
The port is experiencing a PoE failure.
POST has failed on the port.
The port is not supplying PoE power.
Flashing yellow (IRF mode)
The port status LEDs on the switch work in
conjunction to indicate the IRF member ID of the
switch. For example, if the LEDs for ports 1 to 5 are
steady green and the other port LEDs are off, the IRF
member ID of the switch is 5.
100/1000Base-X SFP port LED
On the HPE 5510 24G SFP 4SFP+ HI switch, an SFP port LED in conjunction with the port mode LED
indicates the operating state of the SFP port.
Table 28 100/1000Base-X SFP port LED description
Port mode LED
(Mode) status
A link is present on the port and tThe port is operating at 1000
Mbps. The port LED fast flashes when the port is sending or
receiving data.
The port is sending or receiving data at 1000 Mbps.
