Procedure
1. Gently pull the front bezel away from the array chassis.
The bezel includes power connection pins on both sides.
2. Release and remove the empty HDD drive carrier from the chassis.
a) To release the handle, press the release tab toward the carrier LEDs.
b) Pull the handle to remove the empty carrier from the chassis. Use firm, steady pressure.
3. Slide the new drive into the empty drive bay.
Do not force the drive. If it does not slide in smoothly, remove it and try again.
4. Close the drive carrier handle.
Push the handle until it fully engages with the release tab.
5. After no more than two minutes, make sure that the drive operation LED is green.
If the LED does not light, remove and reinsert the drive. If unsuccessful, contact HPE Support.
Upgrade Procedures 111
