31 Right front rack postChassis
2 4Left rail assembly Right rail assembly
4. Secure the chassis to the rack.
The chassis has two handles. Each handle has a thumbscrew that holds the chassis to the rails so it does not slide out of
the rack. Tighten the thumbscrew in each handle until secure.
Connect the Power to the Expansion Shelf
Before you begin
Before you perform this task, you must have already installed the HPE expansion shelf in a rack or enclosure.
Install the Expansion Shelf 64
