41 Right rail assemblyLeft front rack post
2 5Left rail assembly Keeper latch
3 Right front rack post
3. Slide the chassis into the rack.
CAUTION:
The chassis weighs over 52 kg (115 lb). Always use at least two people or a server lift when lifting the chassis.
a) Insert the chassis into the rack, back side first. Be sure the inner rails insert into the outer rails.
b) Gently slide the chassis into position.
When you hear a click, the inner rails have locked into the rail assembly.
Install the Expansion Shelf 63
