Maximum Link DistanceCable GradeCable Grade
20 meters (65 ft)50 μm multimode 500MHz OM232G FC
70 meters (229 ft)50 μm multimode 2000MHz OM3
100 meters (328 ft)50 μm multimode 4700MHz OM4
Note: HPE recommends OM3 or better Fibre Channel (FC) cables.
Table 28: Fibre Channel Cabling
Maximum Distance by Optical Cable/Media TypeSpeedCable Grade
OM4 50μm multi
mode 4700 MHz
M6
OM3 50μm multi
mode 2000 MHz
M6
OM2 50μm multi
mode 500 MHz M6
OM1 62.5μm
multi mode 200
MHz M6
400 m380 m150 m70 m4 GbpsShort Wave
190 m150 m50 m21 m8 Gbps
125 m100 m35 m15 m16 Gbps
Note: Short Wave Cable Grade and Speeds correspond to four types of Maximum Distance by Optical Cable/Media.
Direct Attach Copper
All model arrays also support SFP+ Direct Attach, also known as 10GSFP+Cu. This IEEE Standard network topology uses
10Gb Ethernet over twinaxial copper cables that plug directly into SFP sockets. No transceivers are used.
Direct Attach twinaxial can be designed as "Active" or "Passive" cables, and can have a maximum link distance of about 10
meters (33 feet). HPE storage arrays support Passive Direct Attach twinaxial cables of the appropriate length. Active Direct
Attach twinaxial cables are not currently supported.
Note: HPE does not supply 10GSFP+Cu cables.
Statement of Volatility
HPE Alletra 5000, Nimble Storage HFxx Arrays
Description - Below are the identifications of all the volatile and non-volatile devices found in the HPE Alletra 5010, 5030,
and 5050 and the Nimble Storage HF20, HF20C, HF20H, HF40, and HF60 model arrays.
Table 29: Table of Volatile and Non-Volatile Devices
Procedure to ClearUser Data?LocationQuantityNon-Volatile or
Volatile
Item
Remove AC and
CMOS Battery for 5
minutes
NoMotherboard2Non-VolatilePCH
Use Programmer to
erase
NoMotherboard2Non-VolatileBIOS FW Flash
Hardware and Model Specifications 146
