HPE Nimble Storage HF Series User Manual

Figure 9: Array interface example (Ethernet ports)
71 eth3aeth0a
2 8eth0b eth3b
93 SAS Outeth1b
4 10eth1a SAS Out
115 Serial porteth2a
6 eth2b
Figure 10: Array interface example (Ethernet and Fibre Channel ports)
71 fc3aeth0a
2 8eth0b fc3b
93 SAS Outeth1b
4 10eth1a SAS Out
115 Serial porteth2a
6 eth2b
For more information on SFPs and connecting 10GbE ports to your array, see SFP Specifications on page 141.
Install the HPE Storage Array 18
