HPE Nimble Storage HF Series User Manual

Figure 24: Array controller LEDs (Ethernet and Fibre Channel shown)
41 16Gb/s Fibre Channel HBAs10GBaseT Ethernet speed
2 510GBaseT Ethernet link Out LED
63 In LEDController status
Table 7: Controller LEDs
StatusLED
Flashing indicates network activityEthernet link
• Green: 10Gb/s
• Amber: 1Gb/s
• Off (Dark): 10/100Mb/s, no connection
Ethernet speed
• Solid green indicates the controller is running and system
status is healthy
• Blinking green indicates the system is operating in a de-
graded state, such as loss of redundant power supply or
fan
• Blinking amber indicates an impending failure, although
the system is still operating
• Solid amber indicates that the system is halted or has
failed
Controller status
Array Components 57
