Description Spare part number
1U x16 half height, half length left PCIe riser card P13221-001
2U x16 full height, full length left PCIe riser card P13292-001
2U x8 half height, half length right PCIe riser card P13222-001
2U x8 full height, full length left PCIe riser card P13223-001
For more information on removal and replacement procedures, see Removing and replacing the PCIe riser on page 156.
Network riser spare part
Customer self repair on page 179: Mandatory
Description Spare part number
4x10G QSFP+ Network riser P13224-001
1G RJ45 Network riser P20590-001
10G SPF+ Network riser P20589-001
For more information on removal and replacement procedures, see Removing and replacing the network riser on page 154.
HPE ProLiant e910 NVMe M.2 enablement board spare part
Customer self repair on page 179: Mandatory
Description
Spare part number
Four-slot NVMe M.2 enablement board P13205-001
For more information on removal and replacement procedures, see Removing and replacing the NVMe M.2 enablement
board on page 155.
GPU Power Enablement kit
Customer self repair on page 179: Optional
Description
Spare part number
e910300W GPU power enablement board P13204-001
Signal cable P13960-001
For more information on removal and replacement procedures, see Removing and replacing the GPU power enablement
board on page 159.
140 Illustrated parts catalog
