HPE ProLiant e910

To replace the component, reverse the removal procedure.
Removing and replacing the GPU power enablement board
The GPU power enablement board is installed for 2U e910 server blade only.
Prerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
Procedure
1.
Power down the server blade.
2.
Remove the server blade from the chassis.
3.
For 2U server blade,
remove the top cover.
4.
Disassemble the top cover.
5. Disconnect the cables connected to the GPU power enablement board.
6. Remove the expansion card installed.
Removal and replacement procedures 159
