The name of the iLO firmware image file is similar to iLO 5_<yyy>.bin, where <yyy> represents the firmware
version.
Obtaining supported server firmware image files
Procedure
1. Navigate to the following website: http://www.hpe.com/support/hpesc.
2. To locate and download an Online ROM Flash Component file, follow the onscreen instructions.
3. If you downloaded a Windows component:
a. Double-click the downloaded file, and then click the Extract button.
b. Select a location for the extracted files, and then click OK.
4. If you downloaded a Linux component:
a. For Linux components, depending on the file format, enter one of the following commands:
•
#./<firmware_file_name>.scexe –unpack=/tmp/
• #rpm2cpio <firmware_file_name>.rpm | cpio -id
b.
(Optional) If you are working with an Innovation Engine or Server Platform Services (SPS) firmware component, locate
the <firmware_file_name>.zip file, and extract the binary file.
Server firmware file type details
• When you update the system ROM, you must use a signed image or the signed ROMPAQ image:
◦ Signed image example:
http://<server.example.com:8080>/<wwwroot>/P79_100_10_25_2013.signed.flash
◦ Signed ROMPAQ image example:
http://<server.example.com>/<wwwroot>/CPQPJ0612.A48
• The Power Management Controller, chassis firmware, and NVMe backplane files use the file extension .hex. For example,
the file name might be similar to ABCD5S95.hex.
• The System Programmable Logic Device (CPLD) firmware file uses the file extension .vme.
• The Innovation Engine (IE) and Server Platform Services (SPS) firmware files use the file extension .bin.
Viewing software information
Prerequisites
To display a complete set of data on this page, AMS must be installed.
Procedure
1. Click Firmware & OS Software in the navigation tree, and then click the Software tab.
2. (Optional) To update the software information data, click .
Using HPE iLO 5 81
